EPDM dense sealing strip

EPDM solid seal strip is a sealing product made of high-quality EPDM rubber (EPDM). Compared with foam seal strip, solid seal strip has higher density and strength, and can provide excellent sealing performance and mechanical stability. It has excellent aging resistance, ozone resistance, UV resistance and chemical corrosion resistance, and is widely used in automobile, construction, machinery and other industries.

specification

Material: EPDM

Diameter: 5mm - 100mm (customizable)

Size: Customized as per customer s requirements

Surface treatment: smooth textured or other special treatments

Color: Black gray or customized

Customization: Materials sizes and surface treatments can be customized according to specific needs

Product Catalog
Related Products
  • Quality Control:

We strictly follow the ISO 9001 quality management system to ensure that each batch of products undergoes strict quality inspection. Each seal strip undergoes multiple tests such as physical properties, chemical composition, aging resistance and weather resistance to ensure that product performance meets or exceeds industry standards.

  • Applicable scenarios:

EPDM dense seal strips are widely used in the following fields:

Automotive industry: Car doors, windows, engine hood sealing

Construction industry: Doors, windows, curtain wall sealing

Mechanical equipment: Sealing and protection of various mechanical equipment

  • Installation method:

Cleaning: Ensure that the installation surface is clean and dry, free of oil and dust.

Measuring and cutting: Measure and cut the seal strip according to actual needs.

Pasting: For self-adhesive seal strips, tear off the adhesive paper and paste directly; non-self-adhesive types require special glue or fixings.

  • Precautions:

Storage: The seal strip should be stored in a cool, dry and ventilated place, away from direct sunlight and high temperature environment.

Protection: Avoid contact with oils, solvents and other chemicals to prevent damage to the performance of rubber materials.

  • Packaging and transportation methods:

Packaging: Products are packed in plastic bags, cartons or wooden boxes, and customized packaging is provided according to customer needs.

Transportation: Delivery by land, sea or air to ensure that the product is not damaged during transportation.

  • FAQ:

1. What is the temperature range of EPDM dense sealing strips?

- The temperature range of EPDM dense sealing strips is usually between -40°C and +120°C, which is suitable for most industrial and commercial environments.

2. Is the sealing strip waterproof?

- Yes, EPDM dense sealing strips have excellent waterproof properties and can effectively prevent moisture penetration.

3. Can this product be recycled?

- EPDM rubber material has good recyclability and can be reused after professional treatment.

4. How to deal with damaged sealing strips?

- Damaged sealing strips should be properly handled and avoid being discarded at will. You can contact the local waste disposal department for environmentally friendly treatment.

5. Do you provide samples?

- Yes, we can provide samples for customers to test and evaluate, please contact our sales team for details.

Sealing Strip Production Process

Raw Material Procurement
The company rigorously selects high-quality suppliers to procure rubber, plastics, and various additives that meet national and international standards, ensuring material quality.
Raw Material Inspection
Advanced equipment and a professional team are employed to comprehensively inspect raw materials, including their physical and chemical properties, ensuring they meet production requirements. Only materials that pass inspection proceed to the production phase.
Compounding and Mixing
Accurate compounding and mixing are conducted according to product formulation ratios. High-efficiency mixing machines ensure thorough blending of raw materials to achieve uniform consistency. The mixed materials undergo a maturation period to ensure material stability.
Extrusion Molding
Maturation-treated mixed materials enter the extrusion molding process. Different extruders and molds are used based on product shapes and specifications. Stringent control of parameters such as temperature, pressure, and speed ensures products meet design requirements in terms of size and appearance.
Vulcanization and Cooling
Products after extrusion molding undergo vulcanization to enhance their physical properties and durability. Vulcanization occurs under high temperature and pressure conditions using vulcanization machines to ensure uniform curing. Post-vulcanization, products undergo cooling to further stabilize performance.
Cutting and Processing
Cooled products enter the cutting and processing stage. Precision cutting and further processing such as edge trimming and hole punching are performed according to specific product requirements. During processing, strict control of dimensions and accuracy ensures products meet design specifications.
Surface Treatment
Processed products undergo surface treatment as required, such as spraying, impregnation, or bonding. Surface treatment enhances product appearance and improves properties such as corrosion resistance, waterproofing, and wear resistance.
Final Inspection
All finished products undergo rigorous final inspection. The company utilizes advanced testing equipment and a professional quality inspection team to comprehensively test dimensions, physical properties, chemical properties, etc. Only products that pass inspection are packaged and ready for shipment; non-conforming products are reworked or scrapped.
Packaging and Storage
Inspected and approved products proceed to packaging. Suitable packaging materials and methods are selected based on product characteristics and customer requirements to ensure products remain undamaged during transportation and storage. After packaging, products are stored in the warehouse awaiting shipment.
